M-BUS to BACnet IP & MS/TP Server Gateway - INBACMEB1200000

Giá bán: Liên hệ

Mã sản phẩm: INBACMEB1200000

Thương hiệu: HMS

Tình trạng: Hết hàng

ORDER CODES:

INBACMEB1200000: 120devices

Tư vấnhotline0965746247

M-BUS to BACnet IP & MS/TP Server Gateway

Integrate any M-Bus device with a BACnet BMS or any BACnet IP or BACnet MS/TP controller. The aim of this integration is to make accessible M-Bus devices, its registers and resources from a BACnet based control system or device, as if it was a part of the own BACnet system and vice-versa.

FEATURES

  • UL Certified
  • BTL Certified
  • Support for BACnet IP Client
  • BACnet Advanced features available (Trend logs, Calendars, etc.)
  • M-BUS line scan (meter detection) and register discovery
  • Embedded M-Bus level converter
  • Easy integration & updates with Intesis MAPS

Use Case

Integration of M-Bus meters into a BACnet installation.

IBOX-BAC-MBUS

Description

This bidirectional gateway provides a straightforward and fast integration thanks to its unique onboard features.

The BTL mark ensures 100% compatibility and, at the same time, guarantees a seamless integration with any BACnet device.

The configuration is carried out using the Intesis MAPS software. This one allows you to define your own settings for the device. Also, it will be able to download all the available project templates or to import any created/exported project template on your computer.

ORDER CODES:

INBACMEB0100000  M-BUS to BACnet IP & MS/TP Server Gateway - 10 devices
INBACMEB0200000  M-BUS to BACnet IP & MS/TP Server Gateway - 20 devices
INBACMEB0600000  M-BUS to BACnet IP & MS/TP Server Gateway - 60 devices
INBACMEB1200000  M-BUS to BACnet IP & MS/TP Server Gateway - 120 devices
