Vaisala HUMICAP Humidity and Temperature Probe HMP1 is designed for measuring ambient measurement in indoor spaces. HMP1 can be directly connected to Indigo200 series transmitters to form a single wall-mounted unit. Its probe head and body are integrated to a single unit and it uses the miniature 5 mm (0.2 in) diameter HUMICAP sensor and head for great stability and fast response time. HMP1 is part of the Indigo product family and compatible with Indigo200 and Indigo500 Series Transmitters. HMP1 can also be used with the Vaisala Insight PC Software for data visualization, easy probe configuration, and self-calibration.
Dimensions
Key Benefits
Wall Mounting With Indigo Series Transmitters
HMP1 is part of the Vaisala Indigo family, so it can also be used with the Vaisala Indigo500 and Indigo200 transmitters to form a wall-mounted transmitter. The transmitters offer various additional benefits, such as display for data visualization and easy access to probe configuration, as well as more extensive options for connectivity, supply voltage, and wiring. Whether using HMP1 standalone or with an Indigo transmitter, it can be connected to the free Vaisala Insight PC software for easy field calibration, probe configuration, and device analytics.
Fast response time and excellent measurement performance
The probe head and body of HMP1 are integrated into a single unit. HMP1 uses the same miniature HUMICAP® sensor and probe head as HMP9. This compact probe ensures fast response time and excellent measurement performance – even in rapidly changing environments.
Chemical purge minimizes effects of contaminants
In environments with high concentrations of chemicals and cleaning agents, the chemical purge option helps to maintain measurement accuracy between calibration intervals. The chemical purge involves heating the sensor to remove harmful chemicals. The function can be initiated manually or programmed to occur at set intervals.
Measurement Performance | |
Relative Humidity | |
Measurement range | 0 … 100 %RH |
Accuracy at +23 °C (+73.4 °F) 1) 2) | ±1.0 %RH (0 … 90 %RH) |
Factory calibration uncertainty 3) | ±0.7 %RH (0 … 40 %RH) ±1 %RH (40 … 95 %RH) |
Sensor | HUMICAP I |
Temperature | |
Measurement range | −40 … +60 °C (−40 … +140 °F) |
Accuracy at +23 °C (+73.4 °F) 1) 2) | ±0.2 °C (±0.36 °F) |
Factory calibration uncertainty 3) | ±0.1 °C (±0.18 °F) at +23 °C (+73.4 °F) |
1) Defined against calibration reference. Including non-linearity, hysteresis, and repeatability. 2) In typical room conditions. 3) Defined as ±2 standard deviation limits. Small variations possible; see calibration certificate. |
|
Operating Environment | |
Operating temperature | −40 … +60 °C (−40 … +140 °F) |
Storage temperature | −40 … +60 °C (−40 … +140 °F) |
Measurement environment | For air, nitrogen, hydrogen, argon, helium, and oxygen 1) |
IP rating | IP50 |
1) Consult Vaisala if other chemicals are present. Consider safety regulations with flammable gases. | |
Inputs and Outputs | |
Operating voltage | 15 … 30 V DC |
Current consumption | 2 mA typical, 200 mA max. |
Digital output | RS-485, non-isolated |
Protocol | Modbus RTU |
Output Parameters | |
Absolute humidity (g/m3) | Relative humidity (%RH) |
Absolute humidity at NTP (g/m3) | Relative humidity (dew/frost) (%RH) |
Dew point temperature (°C) | Temperature (°C) |
Dew/frost point temperature (°C) | Water concentration (ppmv) |
Dew/frost point temperature at 1 atm (°C) | Water concentration (wet basis) (vol‑%) |
Dew point temperature at 1 atm (°C) | Water mass fraction (ppmw) |
Dew point temperature difference (°C) | Water vapor pressure (hPa) |
Enthalpy (kJ/kg) | Water vapor saturation pressure (hPa) |
Mixing ratio (g/kg) | Wet-bulb temperature (°C) |
Compliance | |
EU directives | EMC Directive (2014/30/EU) RoHS Directive (2011/65/EU) |
EMC compatibility | EN 61326‑1, industrial environment |
Compliance marks | CE, China RoHS, RCM, WEEE |
Mechanical specifications | |
Connector | M12 5-pin A-coded male |
Weight | 38 g (1.34 oz) |
Materials | |
Probe | AISI 316L |
Probe body | PBT |
Accessories | |
Indigo USB adapter 1) | USB2 |
1) Vaisala Insight software for Windows available at www.vaisala.com/insight. |
