Valve test bench (CSV)

Giá bán: Liên hệ

Mã sản phẩm: Đang cập nhật

Thương hiệu: Metrus

Tình trạng: Còn hàng

Valve test bench (CSV) for control and shut-off valves Most international valve standards will demand the valve to NOT be exposed to high clamping force prior to the increase of testing pressure – a requirement hardly possible to be achieved with hydraulic clamping. Since more than 40 years, METRUS valve test benches...

Tư vấn hotline

0965746247

Trong 1 - 2 Giờ làm việc không bao gồm chủ nhật và ngày lễ

Đổi trả sản phẩm trong vòng 7 ngày nếu có lỗi từ nhà sản xuất

Hotline tư vấn0379 447 488

TÌM HIỂU THÊM

Mô tả

Valve test bench (CSV)

for control and shut-off valves

Most international valve standards will demand the valve to NOT be exposed to high clamping force prior to the increase of testing pressure – a requirement hardly possible to be achieved with hydraulic clamping. Since more than 40 years, METRUS valve test benches are equipped with our superior automatic seal head technology. Those seal heads directly convert test fluid pressure into clamping pressure, ensuring a smooth and linear clamping force increase along with the increase of test fluid pressure.

Info CSV-Series

All CSV models offer the following features:

Stainless steel control cabinet
Anodized, acid proof front panel
Shell test with water up to 600 bar
Seat leakage test with air up to 9 bar
Clamping via automatic seal heads
Air lock free filling
Closed water circuit
Dual chamber SS tank
Stainless steel tubing PN600
Gauge quick connection
Bubble counter (DIN/EN, ASME and API)
Adapted high pressure pump

Options:
